Product Description:
Servo Motor Connectors are essential components designed to ensure reliable and efficient connections between servo motors and their control systems. These connectors are specifically engineered to meet the demanding requirements of various servo motor applications, including Brushless Servo Motors, AC Servo Motor Drivers, and High Torque DC Servo Motors. With a focus on durability, precision, and performance, servo motor connectors play a critical role in the seamless operation of motion control systems in industrial automation, robotics, and other high-performance environments.
One of the standout features of these servo motor connectors is the high-quality contact plating options available. The contacts are plated with silver or gold, with silver plating providing excellent conductivity and corrosion resistance, and gold-plated pins ensuring superior signal integrity and long-lasting performance. This plating combination enhances the electrical connection's reliability, reducing signal loss and minimizing wear over extended periods of use. This makes them ideal for applications where consistent and stable communication between the servo motor and the driver is crucial.
The current rating of servo motor connectors varies depending on the design and application needs, with options typically ranging from 1A to 10A and beyond. This flexibility allows these connectors to be used in a wide range of servo motor systems, from low-power Brushless Servo Motors to more demanding High Torque DC Servo Motors that require higher current capacities. The ability to handle different current ratings ensures that these connectors can support various power levels, accommodating the specific needs of AC Servo Motor Drivers and other servo control units.
Another key attribute of servo motor connectors is the number of contacts they offer. Depending on the complexity of the servo motor system, connectors are available with 4-pin, 6-pin, 8-pin, 12-pin, and even 17-pin configurations. This variety allows for versatile connectivity options, supporting multiple signal lines, power lines, and feedback signals such as encoder outputs and temperature sensors. The availability of different pin counts ensures compatibility with a broad range of servo motor types and control systems, enabling precise control and monitoring of motor performance.
Servo motor connectors come in two main mounting types: panel mount and cable mount. Panel mount connectors are designed to be securely fixed onto control panels or equipment enclosures, providing a stable and accessible connection point for servo motors. Cable mount connectors, on the other hand, are designed to be attached directly to cables, offering flexibility in wiring and installation. This dual mounting capability allows engineers and technicians to select the most suitable connector type based on their system design and installation preferences, enhancing both convenience and reliability.
In applications involving Brushless Servo Motors, the quality and reliability of connectors are paramount, as these motors rely on precise electrical signals for accurate speed and position control. Similarly, AC Servo Motor Drivers benefit from connectors that maintain stable and low-resistance connections to ensure smooth operation and efficient power delivery. High Torque DC Servo Motors, which often operate under high loads and varying conditions, require connectors that can handle higher currents and maintain robust mechanical and electrical integrity.
Overall, servo motor connectors are indispensable components that contribute significantly to the performance and longevity of servo motor systems. Their design considerations, including contact plating with silver and gold pins, current ratings up to 10A and beyond, multiple pin configurations from 4 to 17 pins, and flexible mounting options, make them well-suited for a wide range of servo motor applications. Whether used in industrial automation, robotics, or precision machinery, these connectors ensure that Brushless Servo Motors, AC Servo Motor Drivers, and High Torque DC Servo Motors operate reliably and efficiently, delivering the high performance required in today's advanced motion control systems.
Features:
- Product Name: Servo Motor Connectors
- Termination Type: Crimp/Solder for secure and reliable connections
- Operating Temperature Range: -40℃ to +105℃ for versatile usage in various environments
- Available Genders: 8pin, 4PIN, 6PIN, 12PIN, 17PIN to suit different application needs
- Contact Plating Options: Silver Pin and Golded Pin for enhanced conductivity and corrosion resistance
- Compatible Wire Gauge: 18-24 AWG or more, AWG 3-12 Diameter, ensuring flexibility in wiring
- Designed for use with Electro Hydraulic Servo systems, Brushless Servo Motor, and Hydraulic Brake Motors
Technical Parameters:
| Termination Type |
Crimp / Solder |
| Gender |
4PIN, 6PIN, 8PIN, 12PIN, 17PIN |
| Application |
Industrial Automation (DC Servo Motor Drive, Brushless Servo Motor, AC Brushless Servo Motor) |
| Operating Temperature |
-40℃ to +105℃ |
| Current Rating |
1A, 10A, and more |
| Connector Type |
Servo Motor |
| Insulation Resistance |
Applicable for 6PIN, 7PIN configurations |
| Contact Plating |
Silver, Gold-Plated Pins |
| Number of Contacts |
4PIN, 6PIN, 8PIN, 12PIN, 17PIN |
| Mounting Type |
Panel Mount / Cable Mount |
Applications:
The NO MARK 6FX2003 Servo Motor Connectors are meticulously designed to meet the rigorous demands of industrial automation environments. Originating from China and certified with CE and ISO9001, these connectors ensure superior quality and reliability. With multiple contact options including 4PIN, 6PIN, 8PIN, 12PIN, and 17PIN configurations, they are versatile enough to accommodate a wide range of servo motor applications. Whether you are working with AC Servo Motor Drivers, High Torque DC Servo Motors, or Brushless Servo Motors, these connectors provide secure and stable connections essential for optimal performance.
In fast-paced manufacturing settings, where precision and uptime are critical, these connectors play an integral role in linking servo motors to their respective drivers. Their silver and gold-plated pins ensure excellent conductivity and resistance to corrosion, making them ideal for environments where electrical integrity cannot be compromised. Additionally, the insulation resistance properties of the 6PIN and 7PIN models provide enhanced safety and signal isolation, crucial for avoiding interference in sensitive automation systems.
Applications of the 6FX2003 connectors span various industrial automation scenarios, including robotic arms, CNC machinery, conveyor systems, and packaging equipment. They are suitable for use in systems that require rapid and precise movement, such as those powered by high torque DC servo motors or brushless servo motors, which demand reliable and durable connections to function effectively. The gender-specific designs available allow for easy integration and replacement, reducing downtime and maintenance costs.
With a supply ability of 1000 pieces per day and a minimum order quantity of 100, these connectors are readily available for both small-scale and large-scale projects. Packaging is handled carefully in carton boxes to ensure safe delivery within 1-3 working days. Payment can be conveniently made through T/T or PayPal, allowing for flexible transaction options. Overall, the NO MARK 6FX2003 Servo Motor Connectors are indispensable components that enhance the efficiency, reliability, and longevity of AC Servo Motor Drivers, High Torque DC Servo Motors, and Brushless Servo Motor systems in industrial automation applications.
Customization:
Our Servo Motor Connectors, model number 6FX2003, are designed to meet the demanding requirements of Industrial Automation applications such as Brushless Servo Motor, High Torque DC Servo Motor, and Electro Hydraulic Servo systems. Manufactured with high-quality Metal and Plastic materials, these connectors ensure reliable performance and durability.
With a current rating ranging from 1A to 10A and termination types including Crimp and Solder, the 6FX2003 connectors offer versatile connectivity solutions. Produced under strict quality standards certified by CE and ISO9001, they guarantee consistent quality and safety.
Originating from China, our product is supplied under the brand name NO MARK and is available with a minimum order quantity of 100 pieces. Packaged securely in carton boxes, the connectors are ready for shipment within 1-3 working days, supporting fast delivery to meet your project timelines.
We offer flexible payment terms including T/T and PayPal, and maintain a supply ability of 1000 pcs per day to accommodate bulk orders efficiently. Choose the 6FX2003 Servo Motor Connectors for dependable connections in your Brushless Servo Motor, High Torque DC Servo Motor, and Electro Hydraulic Servo applications.
